CNC Slant Bed Lathe Machine (Model LC-72DW)

Introduction

The CNC Slant Bed Lathe Machine is a high-precision horizontal turning solution designed for medium-duty industrial machining. Built with a rigid slant bed structure and advanced CNC compatibility, it delivers excellent stability, accuracy, and efficient chip removal during continuous operation.

With support for major CNC control systems and a 12-station tool post, this machine is ideal for workshops and manufacturing units requiring reliable performance in metal turning, shaping, and precision component production.

---

Technical Specifications

Feature	Specification
Model	LC-72DW
Machine Type	Horizontal Slant Bed CNC Lathe
Control System Compatibility	FANUC / SIEMENS / SYNTEC / LNC
Number of Axes	2-Axis
Max Workpiece Length	500 mm
X-Axis Travel	220 mm
Z-Axis Travel	550 mm
Tool Post	12 Stations
Spindle Motor Power	15 kW
Positioning Accuracy	±0.003 mm
Repeatability	±0.003 mm
Bed Width	40 mm
Voltage Options	220V / 380V / 440V
Spindle Phase	Single
Machine Weight	4000 kg
Dimensions (L×W×H)	2650 × 1800 × 1740 mm
Warranty	2 Years
Inspection Report	Provided (Video + Test Report)

---

Key Features

• High-precision machining with ±0.003 mm accuracy
• Slant bed design improves chip flow and tool life
• Strong 15 kW spindle motor for stable cutting power
• 12-station tool turret for faster tool changes
• Rigid machine structure reduces vibration during operation
• Compatible with multiple CNC control systems
• Suitable for continuous industrial production
• High repeatability for consistent part quality
• Compact design with strong machining capacity
• Designed for medium-duty metal turning applications

---

Applications

Metal Machining Industry

• Precision shaft production
• Automotive components
• Hydraulic parts
• Mechanical fittings

Manufacturing Workshops

• Small to medium batch production
• Custom metal part fabrication
• Industrial prototyping

Heavy Engineering

• Machine parts production
• Structural metal components
• Industrial equipment manufacturing

---

Product Advantages

• Extremely high machining precision and stability
• Efficient chip removal due to slant bed structure
• Reduced vibration for improved surface finish
• Flexible CNC system compatibility
• Strong durability for long-term industrial use
• High productivity with fast tool indexing

---

Product Description

The LC-72DW CNC Slant Bed Lathe Machine is engineered for precision metalworking tasks requiring tight tolerances and reliable performance. Its rigid slant bed structure enhances cutting stability while improving chip evacuation, resulting in cleaner machining and longer tool life.

With a powerful spindle motor and advanced CNC compatibility, this machine supports complex turning operations across a wide range of industrial applications.

---

Construction Features

• Heavy-duty cast machine bed structure
• Precision-ground slant bed design
• Reinforced spindle assembly
• High-strength tool turret system
• Industrial-grade CNC integration frame

---

Performance Features

• High-speed precision turning capability
• Stable long-cycle operation
• Excellent surface finish output
• Reduced thermal and mechanical deformation
• Efficient multi-tool machining system

---

Conclusion

The CNC Slant Bed Lathe Machine (LC-72DW) delivers high accuracy, strong stability, and efficient machining performance, making it a reliable solution for modern manufacturing environments that require precision metal turning and consistent production quality.
