Overview
The A-30ML Mid-Rise Scissor Lift is a compact and robust solution designed for quick tire replacement, underbody servicing, and side work on vehicles. With a lifting capacity of 3000kg and a maximum height of 1000mm, this unit is ideal for workshops, service stations, and mobile repair teams that need safe and efficient lifting without requiring a full-height post lift system.
This unit offers a pneumatic release system, anti-skid platform, and mechanical safety locks to enhance user safety and operational reliability. The system is powered by a 2.2kW motor and can be operated with 110V, 230V, or 400V power input.
Technical Specifications
| Specification | Details |
|---|---|
| Model | A-30ML |
| Type | Mid-Rise Scissor Lift |
| Lifting Capacity | 3000 kg |
| Max Lifting Height | 1000 mm |
| Minimum Height | 110 mm |
| Lifting Time | 30 seconds |
| Weight | 560 kg |
| Air Pressure Requirement | 6–8 Bar |
| Motor Power | 2.2 kW |
| Overall Length (Platform) | 1910 mm |
| Platform Length | 1400 mm |
| Platform Width (Between) | 850 mm |
| Power Supply Options | 110V / 230V / 400V |
Product Features
- Quick Service Access
Ideal for fast tire changes and light repairs alongside the vehicle. - Flexible Installation
Can be surface-mounted or recessed; optional movable kits available for portable use. - Platform Extension Compatibility
Special design allows for additional platform extensions to accommodate wider vehicles. - Pneumatic Release System
Reduces noise during lowering, enhancing safety and user comfort. - Mechanical Safety Locks
Multi-position locks engage automatically at different lift heights for added security. - Anti-Skid Platform
Surface texture minimizes vehicle slippage and prevents sudden drop-down. - Dual Voltage Support
Compatible with 110V, 230V, and 400V systems, suitable for various workshop setups.
Applications
- Tire shops and service centers
- Mobile vehicle repair teams
- Automotive workshops
- Fleet maintenance facilities
- Garage fit-outs for general car service
Conclusion
The A-30ML Mid-Rise Scissor Lift is a compact, safe, and flexible lifting solution built for modern vehicle service environments. Its fast lift time, strong construction, and multi-voltage compatibility make it an excellent choice for professionals seeking reliability, performance, and portability in their workshop equipment lineup.
